Teardown of OnePlus SUPERVOOC 100W Dual Ports Charger (1A1C)

Yi
8月前Chargers & Cables
0 0

You can buy it on Amazon: https://amzn.to/42hoB7L

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
Today, we gonna pick up the latest released 100W SuperVOOC charger. It’s equipped with a USB-A and a USB-C port. Both can support up to 100W SuperVOOC protocol. Let’s go ahead and take a look.

Bill of materials (BOM)
------------------------------------------
Input Fuse: WalterFuse
NTC Thermistor: STE 5D-9M
Safety X2 Capacitor: STE
Bridge Rectifier: Pingwei TBMR810
Electrolytic Capacitor: AiSHi RK Series
Master Control Chip: PI SC1738C
SMD Y Capacitor: TRX TBY2101KB, TRX TBY2221KB
Synchronous Rectifier: Infineon BSC0805LS
Solid Capacitor: PolyCap
Protocol Chip: Injoinic IP2738
Output VBUS MOSFET: Pingwei D40N03HL
