Teardown of Satechi 165W GaN Desktop Charger (Four USB-C Ports)

Yi
2 monthsagoChargers
0 0

You can buy it on Amazon: https://amzn.to/3K8rwbX

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
It’s been a while since we posted a teardown video of a Satechi product. The most impressive feature is those four USB-C ports.
And many of you guys requested to take apart this Satechi 165W desktop charger. So, here it comes.

Bill of materials (BOM)
------------------------------------------
Model: ST-UC165GM
Safety X2 Capacitor: JURCC
Bridge Rectifier: GBU806L
Film Capacitor: JK-ET (TQCAP)
Master Control Chip: MPS HR1211
GaN FET (PFC Circuit): GaN Systems GS-065-011-1-L
PFC Rectifier: Global Power G5S6504Z
Electrolytic Capacitor: Chn Cap
MOSFET (LLC Topology): CR Micro HRD65T230D
Resonant Capacitor: JURCC
Blue Y Capacitor: JYA-NAY
Optocoupler: CT1018
Synchronous Rectification Controller: MPS MP6924A
Synchronous Rectification Rectifier: Hunteck HGN046NE6AL
Solid Capacitor: Chn Cap
Protocol Chip: Ismartware SW3516H
Buck MOSFET: Techcode TDM3548, Techcode TDM3478
MCU: MindMotion MM32F0010
