Teardown of UGREEN Nexode 200W Desktop Charger (4C2A)

Yi
August 18, 2022

You can buy it on Amazon: https://amzn.to/3puqSuh

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
Hi, guys. Welcome back to today’s video.
Several days ago, we took apart the charger king, the EGO EXINNO 240W, which can support up to 240W and charge six devices at the same time.
And today, we got another six charging ports desktop charger from UGREEN, which can support up to 200W.
So, ChargerLAB also gonna test and take it apart. Let’s go.

Bill of materials (BOM)
------------------------------------------
Input Fuse: CONQUER (5A 250V)
NTC Thermistor: Shiheng Electronics
Bridge Rectifier: Pingwei GBU608
Film Capacitor: Nissei (1μF 450V)
Master Controller: NXP TEA8918BAT
GaN IC: Innoscience INN650D260A (650V, 260mΩ)
PFC Boost Rectifier: Pingwei DBSC0665W
Filter Capacitor: AiSHi (450V 68μF)
Power Supply Capacitor: Capxon (47μF 35V)
SMD Y Capacitor: TRX
Optocoupler: Everlight EL1019
Synchronous Rectifier Controller: NXP TEA1995T
Protocol Chip: Ismartware SW3516H
Synchronous Buck MOSFET: Allepic AER4061BE
VBUS MOSFET: Pingwei D40N03HL (30V, 5.5mΩ)
MCU: Eastsoft ES7P0693FHTF
