Diamond LED | Teardown of TEGIC CRYSTAL 35W GaN Charger

Yi
October 16, 2023

You can buy it on TEGIC: https://tegic.cc/products/crystal-35

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
It's been a while since we posted the teardown of a unique 30W mini charger from TEGIC. And today, we got a more powerful successor, the TEGIC CRYSTAL 35W Charger. So, are there any changes to its internal components? Let's find out!

Bill of materials (BOM)
------------------------------------------
Model: crystal 35
Input Fuse: Betterfuse
Safety X2 Capacitor: QNR
Bridge Rectifier: MSB40M
Master Control Chip: Dongke DK036G
Power Management IC: Lii Semi LN3210
SMD Y Capacitor: TRX TMY1222M
Optocoupler: EVERLIGHT EL1018
Synchronous Rectifier: Dongke DK5V100R15S
Solid Capacitor: Reloncap
Protocol Chip: iSmartWare SW2325
Output VBUS MOSFET: HRmicro HRT30N08J
