Teardown of MOMAX 100W 7-in-1 GaN Charging Station (With Wireless Charging)

Yi
April 22, 2023

You can buy it on Amazon: https://amzn.to/41jjP8Q

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
Today, we got a 7-in-1 charging station from MOMAX. Except for six USB ports, it also integrates a wireless charging module. Up to 100W output power makes it possible to fast charge your laptop.
Unlike most charging stations we took apart, it comes with a wireless charging module. The four USB-C and two USB-A ports can charge almost all of your devices at once.

Bill of materials (BOM)
------------------------------------------
Model: UM28
Safety X2 Capacitor: ChamPion
Bridge Rectifier: Pingwei TMBF310
Film Capacitor: JURCC
Master Control Chip: MPS HR1211
Electrolytic Capacitor: Junkang
GaN IC (PFC Boost): Navitas NV6127
PFC Boost MOSFET: EoChip CDM0D04065N6
LLC MOSFET: Oriental Semi OSS60R190J
LLC Resonant Capacitor: JURCC
SMD Y Capacitor: TRX TMY1102M
Optocoupler: EL1019
Synchronous Rectification Controller: MPS MP6924A
Synchronous Rectifier: Oriental Semi SFS06R10G
Solid Capacitor: PolyCap
Synchronous Buck Converter: TOLL Microelectronics TMI2283QE
Master Control Chip (Wireless Charging): Celfras
MOSFET (Wireless Charging): Semione PED30D12M
Solid Capacitor (Wireless Charging): APAQ
MCU: Mindmotion MM32F0010
Protocol Chip: Ismartware SW3516H
Synchronous Buck MOSFET: Allepicsemi CWR03N041AP
Output VBUS MOSFET: Allepicsemi CWT3125AP
