ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review

Floyd
4 yearsagoPower Banks
0 0

The ZMI LevPower M10 Power Bank (WPB100) is an all-in-one power bank that's tailored for Apple users with 18W PD bi-directional fast charging, 10W wireless charging, and a convient Lightning input port. It is also MFi certified and Qi certified. Here's our teardown review.


I Design

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

The power bank has an anodized aluminum alloy casing with a matte finish in grey. The wireless charging area is made of plastic anti-slip rubber coating. Our unit is a bundle version which comes with a braided USB-A to Lightning cable (we prefer a USB-C to Lightning cable which can fast charge iPhone 8 or later).

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

From left to right: USB-A port, battery level indicator, USB-C input and output port, Lightning port, and power button.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Model: WPB100

Cell Capacity: 10,000 mAh, 3.7V, 37Wh

Input (USB-C port): USB PD 5V/3A, 9V/2A, 12V/1.5A (18W max)

Input (Lightning port): 5V/2.4A (12W max)

Wireless output power: 7.5W for iPhone 8 / 8 Plus / X / XS / XS Max / XR; 10W for S10 / S10+ / S10e / S9 / S9+ / S8 / S8+ / S7 / S7 edge / Note9 / Note8 / Note5; 5W for other wirelessly-chargeable devices

Output (USB-C alone): USB PD 5.1V/3A, 9V/2A, 12V/1.5A (18W max)

Output (USB-A alone): 5V/2.1A (10.5W max)

Output (USB-C & USB-A): 5.1V/3.6A (18.36W total)

Weight: 10.72 oz (304 g)


II Teardown

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Pry open the top cover.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Remove the bottom and the screws.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Push out internal components from the bottom.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Separate the aluminum alloy metal casing from the internal components.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Below the wireless charging coil is a thermal paste that dissipates heat from the coil. A thermistor is fixed on the surface with high temperature tape.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

On the other side is a lithium polymer battery.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

The battery cell is from ATL (one of the world's largest battery manufacturers),4.35V,10000mAh,37Wh.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Now we separate the wireless charging part from the power bank part.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

First let's take a look at the wireless charging part which consists of a single coil and a slim PCB board.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

A magnetic shield on the back.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Taking a look at the PCBA.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

0.39μF 100V thin film resonant capacitor.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

IDT wireless charging solution with IDT P9237 as main controller chip.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

An 8MHz passive crystal oscillator provides clocking for the wireless charging controller chip.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

IDT solution-specific NAND flash for storing charging configurations.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Two Vanguard Semiconductor VS3618AE NMOS tubes to drive the wireless charging coil.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Taking a lot at the back of the PCBA.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Two MOSFETs with letter code QN3102, to form the wireless charging driver with the VS3618AE.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

BZT52C2V7 Zener diode with letter code W1.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

A thermistor from Fuwen Sensing is attached to the side of the battery cell with high temperature tape.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Let's look at the other side of the PCBA for the power bank function.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Five LED battery level indicators.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Eastsoft MCU, model TR5611.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

NXP 610A3B power management IC.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Two Dialog N40s are used for synchronous rectification boost.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Two Toshiba TPCC8104s are used to switch the output.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

A switch with letter code 8X.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Fitipower FP6606B PD protocol IC.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Battery protection IC with 6DD letter code.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

The chip under the sealing adhesive is a battery protection tube in CSP package.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Take a look at the opposite side.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Silergy SY7215A boost IC with letter code BETBJA which boosts the battery power for the wireless charging part.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

1R5 chip inductor.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

2R2 chip inductor.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

ZMI's in-house P01S mobile bank buck-boost controller.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

From left to right: USB-A port, USB-C input and output port, Lightning input port, and power button.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

Close-up of the power button.

ZMI LevPower M10 Wireless Charging Power Bank (WPB100) Teardown Review-Chargerlab

All the components.


III Conclusion


From a brand with some of the world's best-selling power banks, the ZMI LevPower M10 Power Bank (WPB100) continues the high standard of the Xiaomi-funded ecosystem brand with top-level components, neat layout, and an in-house buck-boost controller IC. The inclusion of a Lightning input port is a nice touch, especially for iPhone users.

At $36, it is also very reasonably priced for a premium power bank that checks all the boxes. But it is not available in the North America yet.


Pros:

18W PD fast charging input and output with 10W wireless charging.

Nice design and finish with top-level components.

Extra Lightning input port.


Cons:

A little on the thick side.


Source: chongdiantou
