Teardown of Anker 65W Mini Power Strip (GaNPrime 615)

Yi
2 monthsagoChargers
0 0

You can buy it on Amazon: https://amzn.to/3v0QfXe

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
If you have been subscribing to our channel for a long time, you will notice that we have made several videos for the Anker GaNPrime series.
And today, we got a 65W GaN power strip, also from GaNPrime series. The mini design and impressive way to store the power cord can improve desktop utilization. So let's go ahead and check its internal structure.

Bill of materials (BOM)
------------------------------------------
Time-delay Fuse: 3.15A 250V
Safety X2 Capacitor: DGCX (0.15μF)
Bridge Rectifier: Pingwei TMBF310
Electrolytic Capacitor: Yongming, AiSHi
Primary Controller (GaN IC): Southchip SC3057
SMD Y Capacitor: TRX TMY1681M
Synchronous Rectifier Controller: Southchip SC3520
Synchronous Rectifier (GaN FET): Innoscience INN150LA070A
Solid Capacitor: Yongming
Protocol Chip: Ismartware SW3536
Output VBUS MOSFET, Buck MOSFET: AOS AON7544
Synchronous Buck Converter (USB-A): Toll Microelectronic TMI2283QE
Current Limiting IC (USB-A): CellWise CW3047
MCU: Eastsoft ES8P5066FJNK

Related Articles:
1. Teardown of Anker 140W PD3.1 USB-C GaN Charger (717 Charger)
2. Teardown of Anker 140W PD3.1 Power Bank (737 Power Bank)
3. Teardown of Anker 65W 2-in-1 Hybrid Charger (733 Power Bank)

65W ANKER GaNPrime power strip
