With USB-C Cable | Teardown of Baseus 65W Elf Power Bank (20000mAh)

Yi
December 30, 2022

You can buy it on Amazon: https://bit.ly/3BziqAf

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
After taking part a 65W power bank from Baseus, ChargerLAB got another 65W power bank from Baseus. But this time, it comes with an undetachable orange cable. You can conveniently charge USB-C devices without a separate cable.
OK. Let's go ahead and take it apart to see what it looks like inside.

Bill of materials (BOM)
------------------------------------------
Four Battery Cells: 5000mAh for each
Battery Protection Chip: CellWise CW1244
Battery Protection MOSFET: AOS AON7534
Master Controller (MCU): Eastsoft HR7P169BFGNF
Protocol Chip: Chipsea CS32G020K8U6
Synchronous Buck-boost Controller: Southchip SC8815
Synchronous Buck-boost MOSFET: AOS AON7534
VBUS MOSFET (USB-C): Goford Semi G16P03
Protocol Chip (USB-A): Ismartware SW3517S
