GaN & PD3.1 | Teardown of UGREEN Nexode 300W 5-in-1 Charger

You can buy it on Amazon: https://amzn.to/48SPTUU

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
ChargerLAB had done multiple charging tests on the UGREEN 300W Nexode 5-in-1 charger. As a multi-port charger, its USB-C1 will not be affected under any circumstances.
To know how it works, we are going to take it apart to see its internal components.

Bill of materials (BOM)
------------------------------------------
Model: CD333
Input Filtering Circuit:
Time-delay Fuse: CONQUER
Bridge Rectifier: GBU1510
Film Capacitor: NISSEI

PFC Circuit:
PFC Boost MOSFET: Navitas NV6128
PFC Boost Rectifier: Global Power G5S06508QT
Electrolytic Capacitor: Acon
LLC MOSFET: Infineon IPL60R125P7
Resonant Capacitor: Faratronic LLC
Synchronous Rectifier Controller: NXP TEA1995

Primary Circuit:
Master Control Chip: NXP TEA2017AAT

Secondary Circuit:
Optocoupler: Everlight
Synchronous Rectifier: Infineon ISC0805NLS
Synchronous Buck MOSFET: iSmartWare RUH4040M2
Solid Capacitor: PolyCap
Buck Controller: iSmartWare SW3566H, SW3516P, SW3526
VBUS MOSFET: RUH4040M2, NCE NCEP3065QU
