Teardown of Motorola Original 125W GaN Charger for edge 30 ultra (MC-1258)

Yi
6 monthsagoChargers
0 0

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
Hi, guys. Welcome back to today's video.
Motorola's recently released MOTO X30 Pro comes with a 125W GaN fast charger. With this charger, the phone can be charged 50% in 7 minutes and fully charged in 19 minutes. And it also supports 100W PD fast charging, which is convenient for charging your laptop and other devices.
Let's take it apart and see what it looks like inside.

Bill of materials (BOM)
------------------------------------------
Varistor: STE 10D561K
Safety X2 Capacitor: STE (0.33μF)
Thermal Fuse: Better Electronics
Bridge Rectifier: LMB10L30
Film Capacitor: STE, CARLI
PFC Boost Controller: Silergy SY5072B
PFC Boost Transistor: Navitas NV6134A
Recovery Diode: ES5JGR
Input Capacitor: SAMXON
Power Supply Capacitor: SAMXON
Primary Controller: ON Semiconductor NCP1342
Primary GaN Power IC: Navitas NV6134A
Synchronous Rectifier Controller: Joulwatt JW7726B
Synchronous Rectifier: Vergiga VSP003N10HS-G
Solid Capacitor: BERYL electronics (470μF 25V)
Blue Y Capacitor: iSND
Optocoupler: EL1019
Protocol Chip: Injoinic IP2726
Output VBUS MOSFET: Vanguard VS3698AE (30V, 3mΩ)
