Teardown of Anker 65W GaN Charger (GaNPrime 735)

Yi
2 monthsagoChargers
0 0

You can buy it on Amazon: https://amzn.to/3GLQah8

If you wanna buy the tester of POWER-Z, you can visit our Amazon store: Click here.

Introduction
---------------------------------------------------------------
We've posted several videos about chargers and power banks from Anker GaNPrime series. And today, we got our hands on a three ports 65W GaN charger from GaNPrime series. It adopts industry's first all-GaN technology to improve performance massively. So let's see how it can achieve this.

Bill of materials (BOM)
------------------------------------------
Input Fuse: Better Electronics (5A 250V)
Safety X2 Capacitor: DGCX
Electrolytic Capacitor: Yongming
Master Controller (GaN IC): Southchip SC3057
SMD Y Capacitor: HolyStone Optocoupler: EL1018
Synchronous Rectification controller: Southchip SC3520
Synchronous Rectifier: Innoscience INN150LA070A
Solid Capacitor: Yongming MCU: Eastsoft ES8P5066FJNK
Protocol Chip: Ismartware SW3536
Buck MOSFET: AOS AONR66406
Current Sense Amplifier: SG Micro SGM8199A1

Related Articles:
1. Teardown of Anker 140W PD3.1 Power Bank (737 Power Bank)
2. Teardown of Anker 120W GaN Charger (GaNPrime 737)
3. Teardown of Anker 65W 2-in-1 Hybrid Charger (733 Power Bank)

65W ANKER GaN GaNPrime
0
The article is originally written by @Yi posted on Chargerlab. All rights reserved.
